Features:
This machine is applicable for huge/super high/super wide/super heavy/super,it satisfies various machining requirements on heavy cutting like drilling/milling on plane/end face/slope/composite guide ways,it can even realize machining at various angle if with milling head 90°/universal milling head.
1.Crossrail can move to the best machining position to realize rough/fine machining on super high/thin workpieces.
2.Arch bridge type structure keeps best machining rigidity&lengthy precision.
3.Hydraulic locking ensures crossrail fixity/safety&keeps it in good condition.
|
model |
units |
XK2010-2 |
XK2014-3 |
XK2016-3 |
XK2020-3 |
XK2020-4 |
XK2020-6 |
XK2025-4 |
XK2025-6 |
|
table width*length |
mm |
800*2000 |
1000*3000 |
1200*3000 |
1600*3000 |
1600*4000 |
1600*6000 |
2000*4000 |
2000*6000 |
|
table moving speed |
mm/min |
30-4000 |
30-4000 |
30-4000 |
30-4000 |
30-4000 |
30-4000 |
30-4000 |
30-4000 |
|
table load |
T |
2 |
5 |
7 |
8 |
12 |
15 |
16 |
20 |
|
main motor power |
kw |
3.7 |
5.5 |
5.5 |
5.5 |
7.5 |
7.5. |
11 |
15 |
|
machining width*length*height |
mm |
1000*2000*800 |
1400*3000*1000 |
1600*3000*1200 |
2000*3000*1200 |
2000*4000*1500 |
2000*6000*1500 |
2500*4000*1500 |
2500*6000*1800 |
|
spindle motor power |
kw |
7.5 |
7.5 |
7.5 |
11 |
11 |
11 |
11 |
11 |
